The NC5200I IP-PBX series supports the greatest number of VoIP protocols: IAX (Inter Asterisk Exchange), H.323, SIP (Session Initiation Protocol), MGCP (Media Gateway Control Protocol), SCCP; The ViVo IP-PBX supports the following Codecs: GSM, G.729, G.723.1, Linear, Mu-Law, A-Law, ADPCM, G.726, ILBC, LPC-10, MP3 (decoding only), G261, G263 ; H263 and H264 for video streaming. The ViVo IP-PBX allows interconnection with the following technologies telephone: Robbed Bit Signaling Types: FXS and FXO, Loopstart, Groundstart, E & M / E & M Wink; Protocols PRI 4ESS, Lucent SE, National ISDN2, Euro ISDN;BRI: Euro ISDN, ISDN4Linux.
Availability: | |
---|---|
Description:
The NC5200I IP-PBX series supports the greatest number of VoIP protocols: IAX (Inter Asterisk Exchange), H.323, SIP (Session Initiation Protocol), MGCP (Media Gateway Control Protocol), SCCP;
The ViVo IP-PBX supports the following Codecs: GSM, G.729, G.723.1, Linear, Mu-Law, A-Law, ADPCM, G.726, ILBC, LPC-10, MP3 (decoding only), G261, G263 ; H263 and H264 for video streaming.
The ViVo IP-PBX allows interconnection with the following technologies telephone: Robbed Bit Signaling Types: FXS and FXO, Loopstart, Groundstart, E & M / E & M Wink; Protocols PRI 4ESS, Lucent SE, National ISDN2, Euro ISDN;
BRI: Euro ISDN, ISDN4Linux.
The ViVo PBX on its top-end model supports up to a maximum of:
-24 analog lines -24 ISDN BRI base -12 PRI lines. Also available as option:
-LCR (routes calls to the operator cheaper for time and type of call routing to GSM cards included, whether they are connected via ISDN port they are connected via external gateway via IP, VoIP services);
-Fax Server Software with automatic routing to Mail.
Description:
The NC5200I IP-PBX series supports the greatest number of VoIP protocols: IAX (Inter Asterisk Exchange), H.323, SIP (Session Initiation Protocol), MGCP (Media Gateway Control Protocol), SCCP;
The ViVo IP-PBX supports the following Codecs: GSM, G.729, G.723.1, Linear, Mu-Law, A-Law, ADPCM, G.726, ILBC, LPC-10, MP3 (decoding only), G261, G263 ; H263 and H264 for video streaming.
The ViVo IP-PBX allows interconnection with the following technologies telephone: Robbed Bit Signaling Types: FXS and FXO, Loopstart, Groundstart, E & M / E & M Wink; Protocols PRI 4ESS, Lucent SE, National ISDN2, Euro ISDN;
BRI: Euro ISDN, ISDN4Linux.
The ViVo PBX on its top-end model supports up to a maximum of:
-24 analog lines -24 ISDN BRI base -12 PRI lines. Also available as option:
-LCR (routes calls to the operator cheaper for time and type of call routing to GSM cards included, whether they are connected via ISDN port they are connected via external gateway via IP, VoIP services);
-Fax Server Software with automatic routing to Mail.
Platform Features:
• Auto response system settable with predefined and customizable messages;
• IVR System (Interactive Voice Response); •Voicemail settable with personalized response for every user;
•Answering service (voicemail) can be checked by phone or web with messages electronic storage;
•LCR management system (call rooting to the cheapest operator per time and type of call
•ARS management (Automatic Route Selection);
•Fax server software with automatic rooting to email box, printers, storage on disc or file server;
•Software to connect via internet to the internal telephone line;
•Hold calls and hold music managements;
•Audio “conference room” with i nternal and external phone numbers;
•Intercom;
•Visually impaired or blind software telephone operator;
•Call forward for busy or not answering user;
•SMS courtesy services for incoming or controlled calls;
•MOBILE Extension
•Building Automation actions
•MESSAGE Switching
•AUTOPROVISIONING
•log File Analyser (also extended)
•Mobile services: receive and send SMS by the PBX;
•It allows to receive mobile calls to the PBX when the mobile phone is shotted off or not available, it allows to call from your own mobile number registered on the PBX;
•“Virtual-Numbering”
•Queue management;
•Call transferring
•Receive and send IM messages by chat gateway;
•Caller number display;
•Block calls in/out with PIN
•Event notifier via SMS and/or Paging (JSM options)
•“do not disturb” with or without secretary/director;
•Settable Numbering plan;
•Out of office notifier
•Responder programmable cascaded;
•Software telephone;
•Caller number and name display for internal calls:
•Gateway DECT via Digital ISDN or LAN IP connection;
•Registrations of calls to activate with or without alert message;
•CDR (Call Detail Reporting) to control statistic data of calls:
•Call-back service;
•“Hunt Group” service, to manage list of numbers to call;
•“Calling group” to manage call flux
•Centralized address book;
•CALL_BACK
•White List and Black list;
•Configuration storage on Cloud server.
•SIP to MODBUS gateway for SCADA monitoring
Platform Features:
• Auto response system settable with predefined and customizable messages;
• IVR System (Interactive Voice Response); •Voicemail settable with personalized response for every user;
•Answering service (voicemail) can be checked by phone or web with messages electronic storage;
•LCR management system (call rooting to the cheapest operator per time and type of call
•ARS management (Automatic Route Selection);
•Fax server software with automatic rooting to email box, printers, storage on disc or file server;
•Software to connect via internet to the internal telephone line;
•Hold calls and hold music managements;
•Audio “conference room” with i nternal and external phone numbers;
•Intercom;
•Visually impaired or blind software telephone operator;
•Call forward for busy or not answering user;
•SMS courtesy services for incoming or controlled calls;
•MOBILE Extension
•Building Automation actions
•MESSAGE Switching
•AUTOPROVISIONING
•log File Analyser (also extended)
•Mobile services: receive and send SMS by the PBX;
•It allows to receive mobile calls to the PBX when the mobile phone is shotted off or not available, it allows to call from your own mobile number registered on the PBX;
•“Virtual-Numbering”
•Queue management;
•Call transferring
•Receive and send IM messages by chat gateway;
•Caller number display;
•Block calls in/out with PIN
•Event notifier via SMS and/or Paging (JSM options)
•“do not disturb” with or without secretary/director;
•Settable Numbering plan;
•Out of office notifier
•Responder programmable cascaded;
•Software telephone;
•Caller number and name display for internal calls:
•Gateway DECT via Digital ISDN or LAN IP connection;
•Registrations of calls to activate with or without alert message;
•CDR (Call Detail Reporting) to control statistic data of calls:
•Call-back service;
•“Hunt Group” service, to manage list of numbers to call;
•“Calling group” to manage call flux
•Centralized address book;
•CALL_BACK
•White List and Black list;
•Configuration storage on Cloud server.
•SIP to MODBUS gateway for SCADA monitoring
Technical Specifications:
Models | 10 | 20 | 50 | 100 | 240 |
Mounting: | Rack 19'' 2U | ||||
Material: | steel -black / Front Grey | ||||
Dimensions (WxHxD): | 482mm x 520mm 88mm (2U) | ||||
Frontal Panel | 1 Power-ON, 1 Reset, led segnaling | ||||
Cooling: | 4 x 8cm Fan Low Noise | ||||
Graphic board: | chipset VIA | chipset intel 946GZ | |||
LAN: | integrata 10/100 Mbps | integrata 10/100/1000 Mbps | |||
Audio: | integrata AC97 | ||||
CPU | mITX 1000 | mITX 1300 | P4/C | Core2DUO | Core2Quad |
RAM | 1GB | 2GB | 4GB | ||
HDD/DOC | 2GB | 4GB | 8GB | ||
CF/ front changeable | 2GB | 4GB | |||
HDD/SSD | / | / | 8GB | 32GB | 64GB |
N° MAX CH suggested | 20 | 40 | 100 | 200 | 512 |
N° MAX FAX together suggested | 1 | 3 | 6 | 18 | 39 |
POWER | AC 220V | ||||
Batteries | 1x7Ah 12v | 2x7Ah 24v | |||
Rear Panel connectors | 1 parallel port, 1 serial port, 2 PS/2 ports, 4 USB 2.0 ports, 1 VGA port,1 LAN port, 1 Audio Speaker/Microphone port | ||||
Expansion Slots | 2x PCI | 3 x PCI |
